SAE1045 1018 Ss400 S45c Cold Drawn Steel Round Bar Hex Steel Flat Bar

Looking for high-quality cold drawn steel bars? Our factory offers a variety of options including SAE1045, 1018, SS400, S45C, round bars, hex bars, and flat bars.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
cold drawn steel
Special Use
Free Cutting Steel, Machine Work
Application
Gears, Shafts, Bolts, Valves, Bushings, Pins, Pipe
Concentricity
Customized
Straightness
0.08mm/400mm
Delivery Time
15-30days
Diameter Tolerance
0.03mm-0.1mm
Transport Package
Exporting Packing or According to Your Special Re
Specification
dia: 4mm-150mm
Trademark
DaJin
Origin
Shandong
Production Capacity
3000tons/Month

Product Description

AISI 1018 Cold drawn steel bar cold rolld steel bars

1.AISI1018 cold drawn steel bar

CD 1018 bar is a low carbon steel with a medium manganese content. Has good case hardening properties, fair machinability and is excellent for cold bending and forming operations. Readily welded and brazed.

2.AISI 1018 Cold drawn steel bar Typical applications

Suitable for general shafting purposes and for applications that do not require the greater strength of high carbon and alloy steels.

3.AISI 1018 cold drawn steel bar main type and avaliable sizes


Round bars 5mm-130mm
Suqare bar 6*6mm-100*100mm
Flat bars 3mm*20mm-50mm*100mm
Hex bars 6mm-100mm
Bar Finsihe Peeled, Cold Drawn, TurnedTurned & Polished, Centreless Ground

4.AISI 1018 Cold drawn steel bar size tolerance

h9,h10,h11 or other tolerance according to client's requirement

5.AISI 1018 Cold drawn steel bar chemical composition(%)

C Si Mn P S
0.15-0.20 0.15-0.35 0.60-0.90 0.030 0.030

6.AISI 1018 Alternative grade in different standard

GB 20Mn
ASTM 1018
JIS S18C
DIN CK18

7.AISI 1018 Typical Mechanical Properties - Cold Drawn and Turned and Polished Condition

Tensile Strength,Mpa Min 440
Yiled Strength,Mpa Min 372
Elongation(%) 15
Reduction of Area(%) 40
Brinell Hardness 126

8.Straightness: 1mm/m(max)
9. Steel bar Packing:
*Bars from different heats will not be mixed and dispatched.
*Bars will be bundles and securely metal strapped in 3 min places of the bar length and tagged properly.
*For further processing products such as cold drawn/peeled or heat treated goods, plastics bag wrapped or pallet loading is available according to customer's demands.

10.Delivery time of steel bar:
7-10days of stock,30 days after order confirmed of new material

11.Payment term:TT or LC

12.Free sample:Yes

13.steel bar Inspection: Spectral Tested, Microstructure Tested,Hardness Test,Macrostructure Test,UT test
14.Our cold drawn factory equipments
We adopt advanced production technology and first-class processing equipments, such as heat treatment furnace, straightening machine, centerless grinding machine, polishing machine, as well as lathing and milling machine etc.

15.Our steel bar mill's certificates

ISO901&ISO.TS16949,ISO4001,OHSAS18001
Special Equipment Manufacturing License of P.R.C for pipeline plate,steel plate for boiler&Vessel;
ISO/TS16949 2009 for Manufacturing of Special steel;
Europe CE Mark Certificate;JIS MARK,KS MARK.

With dynamic and passionate professional sales team and technical team,Our company Dajin make great efforts to integrate China's steel resources and dedication to customers the provision of specialized steel products and services.Hope establish a good relationship with clients, growth together.

AISI 1045 Cold drawn steel bar steel shafts

  1. AISI1045 cold drawn steel bar

CD 1045 bar is a medium carbon range steel that offers better mechanical property advantages over 1018 and other lower carbon steels. It has good heat treatment response and fair welding characteristics.  It can be forged and it is the most common shafting steel in the medium carbon range.

2.AISI 1045 Cold drawn steel bar Typical applications

Shafts for hydraulic and pneumatic cylinders.

3.AISI 1045 cold drawn steel bar main type and avaliable sizes

Round bars 5mm-130mm
Suqare bar 6*6mm-100*100mm
Flat bars 3mm*20mm-50mm*100mm
Hex bars 6mm-100mm
Bar Finsihe Peeled, Cold Drawn, TurnedTurned & Polished, Centreless Ground

4.AISI 1045 Cold drawn steel bar size tolerance

h9,h10,h11 or other tolerance according to client's requirement

5.AISI 1045 Cold drawn steel bar chemical composition(%)

C Si Mn P S
0.43-0.50 0.15-0.35 0.60-0.90 0.030 0.030

6.AISI 1045 Alternative grade in different standard

GB 45#
ASTM 1045
JIS S45C
DIN CK45

7.AISI 1045 Typical Mechanical Properties - Cold Drawn and Turned and Polished Condition

Tensile Strength,Mpa Min 625
Yiled Strength,Mpa Min 530
Elongation(%) 12
Reduction of Area(%) 35
Brinell Hardness 179


8.Straightness: 1mm/m(max)
9. Steel bar Packing:
*Bars from different heats will not be mixed and dispatched.
*Bars will be bundles and securely metal strapped in 3 min places of the bar length and tagged properly.
*For further processing products such as cold drawn/peeled or heat treated goods, plastics bag wrapped or pallet loading is available according to customer's demands.

10.Delivery time of steel bar:
7-10days of stock,30 days after order confirmed of new material

11.Payment term:TT or LC

12.Free sample:Yes

13.steel bar Inspection: Spectral Tested, Microstructure Tested,Hardness Test,Macrostructure Test,UT test
14.Our cold drawn factory equipments
We adopt advanced production technology and first-class processing equipments, such as heat treatment furnace, straightening machine, centerless grinding machine, polishing machine, as well as lathing and milling machine etc.

15.Our steel bar mill's certificates

ISO901&ISO.TS16949,ISO4001,OHSAS18001
Special Equipment Manufacturing License of P.R.C for pipeline plate,steel plate for boiler&Vessel;
ISO/TS16949 2009 for Manufacturing of Special steel;
Europe CE Mark Certificate;JIS MARK,KS MARK.

With dynamic and passionate professional sales team and technical team,Our company Dajin make great efforts to integrate China's steel resources and dedication to customers the provision of specialized steel products and services.Hope establish a good relationship with clients, growth together.

SAE1045 1018 Ss400 S45c Cold Drawn Steel Round Bar Hex Steel Flat BarSAE1045 1018 Ss400 S45c Cold Drawn Steel Round Bar Hex Steel Flat Bar

AISI SAE 1215/JIS SUM23  high-quality free cutting structural steel

Standards:ASTM,JIS,GB,EN(DIN,BS,NF) Or Per as clients' requires.

Product Basic Information:



Material

ASTM 1215

Chemical Composition

Mechanical Properties(In Quenched & Tempered State)

C

0.14-0.20

Tensile strength(MPA)

930

Si

0.15-0.30

Yield strength (MPA)

>1130

Mn

1.140-1.40

Elongation(δ5/%)

->9

Cr

-

Reduction in Area (ψ/%)

45

Ni

-

Impact  (J)



P

≤0.035



 Hardness  (HB)

anneal  28

heating temperature 900C

S

≤0..030

Cu

0.25

Ti

-





2.Product Application Areas:

Our products have been used in all kinds of areas, such as aviation,aerospace,navigation,nuclear energy,chemical industry,

electronic information,achine manufacture, petrochemical, automotive,instrument and meter, Communication ,transportation, and medical instruments, etc.



3.Similar steel grade & equivalent steel materials:

USA

Japanese

Gemany

British

France

heat treatment

Chinese

ASTM&AISI&SAE

JIS

EN DIN

EN BS

EN NF

ISO

GB

1215

SUM23

10S20(1.0721)

------

Y08

the carbon of High quality carbon structural steel  is less than 0.8% of the carbon steel, the steel contains sulfur phosphorus and non-metallic inclusion less than that of carbon structural steel, and mechanical performance is excellent. Mainly used in the manufacture of general structure and the mechanical structure parts, components and building structure and pipe conveying fluid.



Product parameter nformation:

Material

carbon steel

Size

Diameter:4-150mm

Length:500mm-6000mm  custom-made

Origin place

Made In China

Delivery Condition

cold drawn

Surface require

Black,grinding,bright,polish

Heat treatment

Quenched,Tempered,annealed

Packing

seaworthy packing ,wooden case ,carton,woven bag or at client's requires

Delivery time

In 10-50 days

Trade Term

EXW,FOB,CIF

Payments

T/T or L/C at sight

Port

China main Port,such as shanghai,Dalian,Shenzhen port.

MOQ

3 Ton





Other products of the company:



Alloy Steel

5140,5115,5120,5130,5145,4118,4130,4135,6150,5115,4142,4130,4118,6150,4140,4720,4320

,E9310,8620,4340,1547,S42NL

Tool Steel

H13,1.2344,SKD61,D2,SKD11,1.2379,1.2510,01,SKS3,95MnWCr5,D3,SKD1,1.2419,

SKS31,H21,SKD5,1.2581,P20,35CrMo7,1.2738,1.2316,M2,T7,Cr06,SUJ2,t5,t3,t4,M2

Bearing Steel

GCr15,52100,SUJ1,SUJ2,100Cr6,1.2067,55C,8620,4320,9310,440C,M50,8620h

Spring Steel

9260,SUP6,SUP7,1.7108,54SiCr6,1.7102,5155,SUP9,1.7176,5160,1.7177,6150,

SUP10,51CrV4,1.8159,SUP10,

Stainless Steel

317,sus321,1.405,304,SUS304,1.4301,410,SUS410,1.4006,420,1.4021,1.4028,

434,1.4113,316L,SUS316L,1.4435,630,1.4542,431,1.4057,201,202,301,304,305.316

 carbon steel            1008,1010,1020,0.35,1040,1045,1050,1055,1060,1065,1070
