Product Description
Q235 SS400 Carbon Steel Round Bar Mild Steel rod with JIS A36 carbon 3mm round shape For Sale
| product name | Carbon Steel Bar | |
| Width(mm) | 5mm*5mm-500*500mm | |
| Length(mm) | 600-12000mm | |
| Technology | hot rolled/cold rolled/cold drawn | |
| Material | ASTM | A36, Grade 36, Grade 40 Grade 50, Grade 60, Grade 80,etc |
| DIN | Ck10,Ck15,Ck22,Ck25,Ck30,Ck35,Ck40,Ck45,Ck50, 30Mn4,40Mn4,etc | |
| BS | 040A04,095M15,045M10,080A40,045M10,080M50,etc | |
| GB | Q195, Q215, Q235, Q255, Q275, Q295, Q345, Q390, Q420, Q500, etc | |
| Standard | GB/T799,ASTM A29,A108,A321,A575,BS970,DIN1652,JIS G4051 | |
| Surface | Black painting, varnish paint, anti rust oil, hot galvanized, cold galvanized, 3PE | |
| Certificates | API5L ISO 9001:2008 TUV CE SGS BV etc | |
| Packaging | Loose package, Packaged in bundles(3Ton Max) , bundled pipes with two slings at the both end for easy loading and discharging, End with Plastic caps or as per requirement | |
| Application | 1. Fluid pipe 2. Power Plant 3. Structure pipe 4. High and low pressure Boiler tube 5. Seamless pipe /tube for petroleum cracking 6. Conduit pipe 7. Scaffolding pipe pharmaceutical andship,building etc. | |
| Tolerance | ±1% | |
| MOQ | 1 ton | |
| Supply Ability | 5000 tons / month | |
| Lead Time | 7-15 working days after the receipt of 30% deposit | |
| Payment Terms | 30%T/T Advance + 70% Balance | |
| Price Terms | FOB, CFR, CIF, EXW | |
| Packing | Standard sea-worthy package or as required | |
| Our main products steel grades. | |||||
| COLD WORK TOOL STEEL | |||||
| Grade | AISI /ASTM | DIN (W.Nr) | JIS | EN/ BS | GB |
| DC53 | higher than D2 | SKD11 | XW-5 | Cr8Mo2Vsi | |
| D2 | D2 | 1.2379 | SKD11 | BD2 | CR12MO1V1 |
| Cr12MoV | CR12MOV | ||||
| D3 | D3 | 1.2080 | SKD1 | BD3 | CR12 |
| O1 | O1 | 1.2510 | SKS3 | 9CRWMN | |
| HMD5 | HMD5 | 7CrSiMnMoV | |||
| 5CrNiMo | L6 | 55NiCrMoV6 | SKT4 | 5CrNiMo | |
| 52100 | 52100 | 1.3505 | EN31 | GCR15 | |
| HOT WORK TOOL STEEL | |||||
| H13 | H13 | 1.2344/1.2342 | SKD61/DAC | 8407 | 4CR5MOSIV1 |
| FDAC | 1.2347 | FDAC | FDAC | ||
| H11 | H11 | 1.2343 | SKD6 | H11 | |
| 3Cr2W8V | H21 | 1.2581/ X30WCrV93 | SKD5 | BH21 | 3CR2W8V |
| PLASTIC MOULD STEEL | |||||
| P20 | P20 | 1.2311 | HPM7/PX88 | 618 | 3CR2MO |
| 718 | P20+NI | 1.2738 | PX4/PX5 | 718 | 3CR2NIMO |
| S136 | 420 | 1.2083 | S-STAR | S136 | 4CR13 |
| NAK80 | P21 /P20+S | 1.2312 | NAK80 | 15NI3MN | |
| HIGH SPEED STEEL | |||||
| M2 | M2 | SKH51 | W6MO5CR4V2 | ||
| M42 | M42 | S2-10-1-8 | SKH59 | W2MO9CR4VCO8 | |
| ALLOY STRUCTURE STEEL | |||||
| Grade | AISI /ASTM | DIN (W.Nr) | JIS | EN/ BS | GB |
| 5120 | 5120 | 1.7027 /21Cr4 | SCr420 | 20Cr | |
| 530M40 /5140 | 530M40 /5140 | 1.7035 /41Cr4 | SCr440 | 40Cr | |
| 5145 | 5145 | Scr445 | 45CR4 | ||
| 4118 | 4118 | 1.7243 /18CrMo4 | SCM418 / SCM420 | 20CrMo | |
| 4135 | 4130 | 1.7218 /25CrMo4 | SCM430 | 708A25/ 708M25 | 30CrMo |
| 4140 | 4140 | 1.7225 /42CrMo4 | SCM440 | EN19/ 709M40 | 42CrMo |
| 4340 | 4340 | 1.6582/ 34CrNiMo6 | SNCM 439/ SNCM8 | EN24/ 817M40 | 40CrNi2Mo |
| 8620 | 8620 | 1.6523/ 21NiCrMo2 | SNCM220 | 805M20 | 20CrNiMo |
| CARBON STEEL | |||||
| 20 | 1020 | C22. CK22 | S20C | EN3B /070M20 | 20 |
| 35 | 1035 | C35.CK35 | S35C | 35 | |
| 45 | 1045 | C45.CK45 | S45C | EN8D/C45E | 45 |
| 50 | 1050 | CK53 | S50C | EN9/070M55 | 50 |
| Q355 | S355J /ST52 | EN14 | Q355 | ||
| 30Mn | 1030.1033 | S30C | 30Mn | ||
| 30Mn2 | 1330 | 30Mn5 | SMn433h | 30Mn2 | |
| STAINLESS STEEL | |||||
| steel grades: 304, 304L, 316, 316L, 321, 410 430, 431, 2205, 2304, 2507. F53, F55 | |||||
Chemical composition
| C | Si | Mn | P | S | Cr | Mo |
| 0.38-0.43% | 0.10-0.35% | 0.75-1.00% | ≤0.035% | ≤0.040% | 0.80-1.10% | 0.15-0.25% |
Equivalent Steel Grade
Din 1.7225
42CrMo4
JIS SCM440
GB 42CrMo
ASTM 4140
Mechanical Properties
| Tensile Strength (MPA) | Yield Strength (MPA) | Reduction (%) | Elongation (10%) | Impact Strength (Aku2/J) | Hardness (HB) |
| 1080 | 930 | 12 | 45 | 63 | Anneal≤217HB Q+T 28-32HRC |
Cold drawn steel types, shapes and sizes we can offer
besides the below shapes and sizes,we can also manufacture it based on customer's requests and customize different shapes and sizes.| Shapes | Sizes | Processing |
| Steel Round Bar | 5mm to 63.5mm | Cold Drawn |
| Steel flat Bar | 63.5mm-120mm | smooth-turned and polished. |
| Cold drawn steel square bar | 5*5mm to120*120mm | Cold Drawn |
| Cold drawn steel hex bar | 5mm to120mm | Cold Drawn |
| Cold drawn steel hexagonal bar | 5mm to 120mm (side to side) | Cold Drawn |
| Straightness | Max 1mm/m | |
| Tolerance | h9 h10 h11 or as required | |
| Dimension (mm) | Tolerance deviation grade | |||||
| Grade h8 | Grade h9 | Grade h10 | Grade h11 | |||
| 3.01-6.0 | 0-0.012 | 0-0.018 | 0-0.030 | 0-0.048 | 0-0.075 | |
| 6.01-10.0 | 0-0.015 | 0-0.022 | 0-0.036 | 0-0.058 | 0-0.090 | |
| 10.01-18.0 | 0-0.018 | 0-0.027 | 0-0.043 | 0-0.070 | 0-0.110 | |
| 18.01-30.0 | 0-0.021 | 0-0.033 | 0-0.052 | 0-0.084 | 0-0.130 | |
| 30.01-50.0 | 0-0.025 | 0-0.039 | 0-0.062 | 0-0.100 | 0-0.160 | |
| 50.01-80.0 | 0-0.030 | 0-0.046 | 0-0.074 | 0-0.120 | 0-0.190 | |
| h7 :grinding product h8 :high-precision cold drawn product h9:precision cold drawn product | h10:standard cold drawn product h11:special shaped cold drawn product | |||||
P roduct length(mm) & diameter
| Product variety | The length of finished product | Length tolerance |
| Cold drawn product | 1000-6000 | 0-+20 |
| Grinding product | 1000-4000 | 0-+20 |
| Product mode | Straightness tolerance |
| Standard cold drawn | 0.7/1000~0.5/1000 |
| Precision and high precision | 0.4/1000 |
| Product mode | Grinding | High precison cold drawn | Precision cold drawn | Stardard cold drawn |
| Surface roughness Ra(um) | 0.40 | 0.80 | 1.60 | 3.20 |
| Type of steel | GB | ASTM(SAE) | JIS |
| Carbon steel Low alloy steel | Q195,Q215, Q235,Q345 | A285MGr.B A570MGr.A | SS330 SS400,SS490... |
| Quality carbon steel | 10,20,35,40,60 20Mn,25Mn, 35Mn,40Mn | 1010,1020,1035, 1045,1060,1022, 1026,1037,1039 | S10C,S20C, S35C,S45C... |
| Alloy structure steel | 20Mn2,40Mn2,20Cr,40Cr, 20CrMo,35CrMo,42CrMo, 20CrMnTi,20Cr2Ni4, 40CrNiMo | 1320,1345,5120, 5140,4118,4135, 4140,3316,4340 | SMn420,SMn438, SCr420,SCr440 SCM430,SCM435 SCM440,SCN815 SNCM439 |
| Cold heading steel | ML10,ML20,ML30, ML35,ML35CrMo, ML42CrMo,ML15MnB | 1012,1020,1030 1034,4135,4140, 1518 | SWRCH10R SWRCH20K SWARCH35K SNB7 |
| Spring steel | 65Mn,60Si2Mn,50CrVA | 1066,6150 | SCP6,SCP10 |
| Bearing steel | GCr15 | E52100 | SUJ2 |
| Stainless steel | 1Cr13,2Cr13 | 412,420 | SUS410,SUS420 |
| Tooling steel | T8,T10 W6Mo5Cr4V2 | W1A-8, W1A-9.5,M2 | SK7,SK4,SKH9 |
| Free cutting steel | Y12,Y12Pb,Y15, Y15Pb,Y40Mn | 1212,11L08,1215 12L13,12L14,1141 | SUM21,SUM32, SUM22L,SUM42... |
Carbon/alloy square/round steel bar is ideal for many industrial products and applications where strength and durability are required. Characteristics of carbon steel bars are based on the carbon content. Increased carbon content will raise carbon steel's hardness and strength. Inversely, lower carbon content results in a softer (mild) carbon steel that is easier to machine and weld.
The type of carbon steel needed is generally based on the application requirements. If you need assistance in determining the right carbon steel bar for your job our sales team is happy to help. Contact us on how we can help you with your next project.
