Product Description
5.5mm 6.0mm spring wire SAE1008b S45C SWRM STKM11A steel wire Steel Wire Rod in Coils
Wire rod is a so-called long product which is formed into coils and used as a semi-finished product:
1. low carbon wire rod is used
for the production of welded wire mesh for the construction industry and for the production of drawn wire (raw, annealed and
coated).
2. Drawn wire, in turn, is made from medium and high carbon wire.
3. In addition to wire rod made of special steels for further processing in forging, drawing or pressing methods, it is also used as welding rod.
Product Name | Hot Rolled Steel Wire Rod in Coils! 5.5mm 6.5mm Low Carbon Steel Ms Wire Rods Factory Price |
Raw Material | A: 1006,1008,1018,Q195, Q235, 55#,60#,65#,70#,72A, 80#,77B,82B B:99.995% Purity Zinc |
Standard | GB/T343; BS EN 10257-1:1998; GB/T3028; BS 4565; ASTM B-498: 1998 GB/T15393; BS EN 10244-2:2001 |
Size | 0.15mm-6.00mm |
Tensile Strength Range | 290MPa-1200Mpa |
Usage | 1. Galvanized steel wire can effectively fix the pipe and has high thermal conductivity. 2. The steel wire mesh has strong tensile strength and can be welded firmly. 3. Galvanized steel rope has the effect of heat preservation and crack prevention. 4. Galvanized steel wire surface is bright, the mesh surface is smooth, and it has good corrosion resistance and oxidation resistance. 5. Buiding , construction, machine made, kitchen ware made, equirment etc. |
Package | Coil, Spool, Wooden Drum, Z2, Z3 |
| wire rod type | A. 45#, 50#, 55#, 60#, 65#, 70# are used to make various steel nails, steel wire ropes, steel strands, hose steel wires, bead steel wires, spring steel wires, etc. B. XGLB72A is used for the production of high-voltage cable ground wires and aluminum-clad steel wires for OPEW optical fiber bundle composite overhead ground wires C.SWRH42A, SWRH62A, SWRH72A, SWRH72B are used to make steel wire rope, aluminum clad steel wire, rubber hose steel wire fishing net line, etc. |
Galvanized steel wire surface treatment:
Technical Data | |||||
Intensity level | Wire diameter | Min. tensile strength | Min. stress with 1% extension | Min. extension percentage | Min. No. of 3600 twist |
mm | Mpa | Mpa | % | ||
General | 1.24~2.25 | 1340 | 1170 | 3.0 | 16 |
2.25~2.75 | 1310 | 1140 | 3.0 | 16 | |
2.75~3.00 | 1310 | 1140 | 3.5 | 16 | |
3.00~3.50 | 1290 | 1100 | 3.5 | 14 | |
3.50~4.25 | 1290 | 1100 | 4.0 | 12 | |
4.25~4.75 | 1290 | 1100 | 4.0 | 12 | |
4.75~5.50 | 1290 | 1100 | 4.0 | 12 | |
High | 1.24~2.25 | 1450 | 1310 | 2.5 | 16 |
2.25~2.75 | 1410 | 1280 | 2.5 | 16 | |
2.75~3.00 | 1410 | 1280 | 3.0 | 16 | |
3.00~3.50 | 1410 | 1240 | 3.0 | 14 | |
3.50~4.25 | 1380 | 1170 | 3.0 | 12 | |
4.25~4.75 | 1380 | 1170 | 3.0 | 12 | |
4.75~5.50 | 1380 | 1170 | 2.0 | 12 | |
Very high | 1.24~2.25 | 1620 | 1450 | 2.0 | 14 |
2.25~2.75 | 1590 | 1410 | 2.0 | 14 | |
2.75~3.00 | 1590 | 1410 | 2.5 | 12 | |
3.00~3.50 | 1550 | 1380 | 2.5 | 12 | |
3.50~4.25 | 1520 | 1340 | 2.5 | 10 | |
4.25~4.75 | 1520 | 1340 | 2.5 | 10 | |
4.75~5.50 | 1520 | 1270 | 2.5 | 10 | |
The spring wire rod is used in the elastic range, and should be returned to the original position after unloading. It is hoped that the smaller the plastic deformation is, the better, so the steel wire should have a high elastic limit, yield strength and tensile strength. The higher the flexure ratio, the closer the elastic limit is to the tensile strength, so the better the strength utilization rate can be improved, and the stronger the spring elasticity will be.
The main types of spring steel wire :
1) Steel wire for cold-rolled springs. This type of spring is used after cold-rolling without heat treatment or only after low-temperature heating, mainly carbon spring steel wire;
(2) Spring steel wire heat-treated after spring coiling, mainly alloy spring steel wire;
(3) Quenched and tempered spring steel wire, also known as oil quenched and tempered spring steel wire;
(4) Stainless spring steel wire, most of this type of steel wire is made of austenitic stainless steel, see alloy steel wire for its production characteristics. In addition, there are deformation heat treatment steel wires under development.
The steel wire is made of high-quality carbon steel, which can achieve high strength after repeated cold drawing and heat treatment. Workplaces such as wet or open air environments can use steel ropes made of galvanized steel wire to enhance rust resistance. The steel wire rope is a flexible rope made of multiple or multiple strands of thin steel wires. The steel wire rope is twisted into strands by multiple layers of steel wires, and then takes the rope core as the center and is twisted into a helical rope by a certain number of strands. In material handling machinery, it is used for lifting, pulling, tensioning and bearing. The steel wire rope has high strength, light weight, stable operation, not easy to break suddenly and reliable operation. Structure: The steel wire rope is mainly constructed with steel wire and rope core. The steel wire rope plays the role of bearing the load, and its performance is mainly determined by the steel wire.
PACKAGE PER BUNDLE
1.According to customer's requirements.
2.Package in PVC material or according to customer's requirements
Shandong Zhuosheng Steel Co.,Ltd is a large-scale iron and steel enterprise integrating iron and steel production, processing, distribution and trade. The comprehensive strength has jumped to the forefront of the domestic steel industry.
Zhuosheng Steel is committed to the research and development, production and processing of carbon steel and profiles and pipes, with strong research and development strength and reliable quality assurance capabilities. Products are suitable for nuclear power, aviation, marine engineering, oil exploration, construction and other fields. The comprehensive annual production capacity is 500,000 tons, and the products are exported to more than 100 countries and regions.
We are based in Shandong Province, China, start from 2011,sell carbon steel coil , carbon steel pipe , carbon steel sheet and rod , stainless steel sheet , pipe rod, steel wire and coil , galvanized steel pipe , rod, coil and GI Sheet to South America(10.00%),South east Asia(20.00%), Africa(20.00%),South Asia(10.00%),Mid East(30.00%),North America(10.00%). There are total about 101-200 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment; the third
party testing is allowed
.we have get the ISO and CE certification .
3.what can you buy from us?
carbon steel and stainless steel and galvanized steel , SUPER GALUMSGLCSGCDUNILUME , SGLD , color bond Hot-Dip Al-Zn Alloy-Coated Steel SheetAl-Zn alloy coated steel , PPGL ,Steel Plate, Roofing Sheet,PPGI,Galvalume Steel,Galvanized Steel ETC.
4. why should you buy from us not from other suppliers?
Shandong Zhuosheng Steel Co.,Ltd belongs to Zhuosheng Group. There are 16 branch companies in our group, including 5 foreign trade companies, 12 domestic trade companies and one steel factory. We can supply all kinds of steel one-stop shop, welcome contact!
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT;
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,MoneyGram,Credit Card,Western Union,Cash;
Language Spoken:English,Chinese,Spanish .
Other related products :
Q1. What are your company's main products ?
A1: Our main products are Steel Plate/Sheet, Galvanized Steel Coil, PPGI,, Steel Pipe/Tube, Aluminum, Steel Sheet Piles etc.
Q2. How do you control quality ?
A2: Mill Test Certification is supplied with shipment, Third Party Inspection is available. and we also get ISO,SGS,Alibaba Verified.
Q3. What are the advantages of your company ?
A3: We have many professionals, technical personnel, more competitive prices and best after-dales service than other stainless steel companies.
Q4. How many coutries you already exported ?
A4: Exported to more than 50 countries mainly from America, Russia, UK, Kuwait, Egypt, Turkey, Jordan,India, etc.
Q5. Can you provide sample ?
A5: We can provide the samll samples in stock for free, as long as you contact us.Customized samples will take about 3-5days.
