Basic Info.
Product Description
Steel Grade | Q195,Q235,Q345,45#, S20C, SAE1010,SAE1020.SAE1045,EN8,EN 19fC45,CK45,SS400 etc | |
Standard | ASTM A615Gr40/60,BSS4449 Gr460B,500B etc | |
Diameter | 5.5-250 mm | |
Length | 3000mm-12000mm or as client's request | |
Straightness | 3mm/M max | |
Tolerance | +0.5mm/-0(dia),+5mm/-0(L) | |
MOQ | 5 tons | |
Heat treatment | Normalized / Annealed / Quenched / tempered | |
Surface | black,mill,polished,brush,etc | |
Test | Ultrasonic test according to SEP 1921-84 G3 C/c | |
Application | Widely used in construction industry for reinforcing concret(Express way; office building, Bridge etc) Trasportation By sea(20' 40' container), parts of larger cross-sections, crankshafts, gears. | |
Packaging | Export standard, seaworthy | |
Delivery time | 10-20 days after confirmed order | |
Container size | 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) | |
40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) | ||
40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High) | ||
Item Type | Diameter (MM) | Length |
Round Bar | 8-400 | 6/9/12m or follow client's requirment. |
Steel Wire Rod | 5.5-34 | Coil |
Steel Rebar | 5.5-40 | Cut to length or Coil |
Category | Grades | Sizes | Standard |
Carbon structure steel | Q195,Q215,Q235,Q275 | 16mm-250mm | GB/T700-2006 |
Low alloy high strength structure steel | Q295,Q345,Q390,Q420, Q460 | 16mm-250mm | GB/T1591-2008 |
Prime Carbon structure steel | 10#, 20#, 35#, 45#, 60#, 20Mn,65Mn,B2, B3,JM20, SH45,S45C,C45 | 16mm-250mm | GB/T699-1999 |
Alloy structure steel | 30Mn2,40Mn2,27SiMn, 42Crmo, 20Cc40Cr,20CrMo, 35CrMo,20CrMnTi, 30CrMnTi,20MnVB, 20MnTiBf 45MnV 20CrNiMo, Q345B, 35MnBM,40MnB,36Mn2V | 16mm-250mm | GB/T3077-1999 |
Spring Steel | 65Mn,60Si2Mn, 50CrVA | 16mm-250mm | GB/T1222-84 |
Bearing Steel | GCr15tGCr15GD,55SiMoV | 16mm-250mm | GB/T18254-2002 |
Structural steels subject to end-quench hardenability requirements | 20CrMnTi,30CrMnTi, 20Cr, 40Crf30CrMo,42CrMoA,27SiMn, 40Mn2H, 20CrNiMo, 40Mn2,q345b,35MnBM, 40MnB,45MnV. | 16mm-250mm | GB/T5216-2004 |
Oil wells structural steel | 37Mn5,36Mn2V | 16mm-250mm | Q/LYS248-2007 |
Marine anchor chain steel | CM490,CM690,M30Mn2 | 16mm-250mm | YB/T66-1987 GB/T18669-2002 |
C | Si | Mn | S | P | Cr | Ni | Cu | Mo |
0.38~0.45% | 0.17~0.37% | 0.50~0.80% | ≤0.035% | ≤0.035% | 0.90~1.20% | ≤0.30% | ≤0.30% | 0.15~0.25% |
Mainly exported to Southeast Asia, North Africa and Middle We have more years experience in supplying enterprises and organizations in the international market. Enable us to complete any order in the shortest time. All the products provided meet the technical requirements and reflect the ideal cost performance.
We will guarantee the quality of your product. Including raw material inspection, supervision of production process,appearance inspection and inspection for the finished products.
We will provide our distinctive packing which improves the protection rate of goods by 30%. We actively seek cooperation with foreign companies, in line with the concept of "excellence, win-win cooperation", with reliable quality and perfect after-sales service system, won the praise of domestic and foreign customers. We sincerely welcome you to our company to negotiate business.
Q: What is your terms of payment?
A: 30% TT in advance and balance paid before loading.
Q: Could you provide sample?
A: Yes, we are honored to offer you samples for quality check.
Q: How is the quality of your products?
A: Our products are manufactured strictly according to national and international standard, and we take a test before delivered out. If you want see our quality certifications and all kinds of testing report, please just ask us for it.
Q: How long does it take for samples and mass production?
A: Usually it will take3-5 days for ready molds, 15-20days for new molds and samples after confirmation, 25-30 days for mass production.
