Product Description
Standard size of aluminum coil | width 1000mm/1250mm/1500mm/2500mm The length can be customized |
Standard size of aluminum plate | 1000mm*2000mm/1250mm*2500mm/1500mm*3000mm/2000mm*6000mm |
0.2mm 0.3mm 0.4mm 0.5mm 0.6mm 0.8mm 1.0mm 1.2mm 1.5mm 2.0mm 2.5mm 3.0mm 4.0mm 5.0mm 6.0mm 8.0mm 10mm 12mm 15mm 20mm 25mm 30mm 35mm 40mm 45mm 50mm 55mm 60mm 65mm 70mm 75mm 80mm 85mm 90mm 95mm 100mm 105mm 110mm 115mm 120mm 125mm 130mm 135mm 140mm 145mm 150mm 155mm 160mm 165mm 170mm 175mm 180mm 185mm 190mm 195mm 200mm | |
aluminum foil | Thickness 0.0045mm--0.2mm Width 10mm-500mm The length supports customization |
Aluminum strip | Thickness 0.2mm-4mm, Width 10mm-1000mm, The length supports customization |
Hardness H0 H12 H14 H18 H22 H24 H26 H32 H111 H114 T4 T6 Other hardness can be customized | |
It can be used for color drawing, embossing, cutting, pattern, strip and other processing | |
The above are the standard common sizes of coil, and customization is supported | |
Material table | Product use | |
1000 series | 1050 | Food, chemical and extrusion coils, various hoses, fireworks powder |
1060 | Chemical equipment is its typical use | |
1100 | Chemical products, food industry installations and storage containers, weldments, heat exchangers, printed boards, nameplates and reflective appliances | |
2024 | Aircraft structures, rivets, missile components, truck hubs, propeller components and other structural components | |
2A12 | Aircraft skin, spacer frame, wing rib, wing beam, rivet, etc., and structural parts of buildings and transportation vehicles | |
2A14 | Free forging and die forging with complex shape | |
3000 series | 3003 | Kitchen utensils, food and chemical products, storage equipment, storage tanks for transporting liquid products, and various pressure vessels and pipelines |
3004 | Chemical product production and storage devices, plate processing parts, building processing parts, building tools and various lamp parts | |
3105 | Room partition, baffle, movable room board, eaves gutter and downpipe, sheet forming parts, bottle caps, corks, etc | |
4000 series | 4032 | Piston, cylinder head |
4043 | Building distribution frame | |
4343 | The products are widely used in automobiles, water tanks, radiators, etc. | |
5000 series | 5052 | Aircraft fuel tank, oil pipe, traffic vehicle and ship sheet metal parts, instruments, street lamp supports and rivets, hardware products, etc |
5083 | Plate Weldments of ships, automobiles and aircraft; Pressure vessel, refrigeration device, TV Tower, drilling equipment, transportation equipment | |
5754 | Storage tanks, pressure vessels, ship materials | |
6005 | Ladder, TV antenna, etc | |
6061 | Pipes, rods, profiles and plates for trucks, towers, ships, trams, furniture, mechanical parts, precision machining, etc | |
6063 | Building profiles, irrigation pipes and extruded materials for vehicles, stands, furniture, fences, etc | |
7075 | It is used for manufacturing aircraft structure and other high stress structural parts and molds with high strength and strong corrosion resistance | |
7175 | High strength structure for forging aircraft. | |
7475 | Aluminum clad and non aluminum clad plates for fuselage, wing frame, stringer, etc. Other parts with high strength and high fracture toughness | |
8000 series | 8011 | The aluminum plate with bottle cap as the main function is also used in radiators, most of which are used in aluminum foil products |
For other materials, you can consult customer service | ||
Q: Are you manufacturer?
A: Yes, we are.
Q:Can you produce according to my requirement?
A:Yes, all the design, size, printing and packaging can be done according to customer's request. About any further detail, please feel free to contact us.
Q: Do you offer free samples?
A: Sure,we are glad to send you free samples for your evaluation.But currently we need you to kindly pay the delivery charge on your side if you'd like to have our samples.
Q: What's your MOQ?
A: Normally 5 Tons are requested as the minimum order quantity on our side.We can accept smaller quantities if the warehouse has the right stock size.
Q:How long is your delivery time?
A: About 15-25 days.
Q:What specification should I tell you if I wanna get the quotation?
A: 1. Alloy 2.Size 3. Temper 4. Estimated quantity
Q: What's your payment term?
A: We accept T/T.
